LED Linear Pixel Facade Light Pakistan — Warm/Cool White/RGB, 8 Pixels/m, IP65 | Contact for Pricing
Problem: Standard facade lights lack pixel-level control for detailed architectural highlighting, color zoning, or dynamic sequences — limiting creative potential for commercial buildings, hospitality venues, and landmark structures in Pakistan. Solution: LED Linear Pixel Facade Light delivers 8 pixels per meter for precise control, IP65 weather resistance, and selectable warm white/cool white/RGB output — all in a slim aluminium+PC profile designed for architectural integration. 💬 WhatsApp to Order
Why Pixel-Controlled Facade Light vs Standard Linear Washers?
| Feature | LED Linear Pixel Facade Light (This Product) | Standard Linear Wall Washer | RGB Flood Light Array |
|---|---|---|---|
| Control Precision | 8 pixels per meter enable individual pixel addressing for detailed effects, color zoning, and dynamic sequences across building facades | Uniform wash output with no pixel-level control; limited to on/off, dimming, or fixed color temperature | Broad flood coverage with RGB mixing; but lacks linear precision for architectural detailing or edge highlighting |
| Architectural Integration | Slim 30×20mm aluminium+PC profile mounts discreetly along building edges, cornices, or reveals; minimal visual impact when off | Often bulkier housing; may require visible mounting brackets that detract from architectural aesthetics | Typically surface-mounted flood fixtures; visible hardware may conflict with minimalist architectural design intent |
| Weather Resilience | IP65 rating + aluminium housing ensures reliability in Pakistan’s monsoon exposure, coastal humidity, and temperature extremes | IP rating varies by model; may require additional sealing for harsh Pakistan climates | Often IP65+ but flood form factor may collect water/debris in horizontal mounting; requires careful orientation |
| Best For | Architectural facade lighting, building outlines, commercial signage accents — where pixel precision, weather resistance, and slim integration are critical | General wall washing, uniform facade illumination — where pixel control is not required and cost minimization is primary | Large-area color flooding, event lighting — where broad coverage outweighs need for architectural precision |
Technical Specifications
| Parameter | Specification |
|---|---|
| Power | 12W — efficient operation for extended facade runs |
| Input Voltage | DC 24V — compatible with standard LED power supplies |
| Pixel Density | 8 pixels per meter — enables detailed architectural lighting effects and color zoning |
| Construction | Aluminium housing with PC (polycarbonate) diffuser — durable, efficient heat dissipation, uniform light output |
| Physical Dimensions | 30mm × 20mm × 1000mm (W×H×L) — slim profile for discreet architectural integration |
| IP Rating | IP65 per IEC 60529 — dust-tight + protected against water jets; suitable for outdoor Pakistan climates |
| Color Options | Variable product: selectable Warm White, Cool White, or RGB output — specify at time of order |
| Applications | Architectural facade lighting, building outlines, commercial signage accents, hospitality exterior highlights |
| Installation Requirement | All electrical connections must be performed by qualified electrician per Pakistan Electrical Safety Code |
Which Application Should You Choose?
| Application | Installation Tip | Why (Pakistan Context) |
|---|---|---|
| Commercial Building Facade Highlighting | Mount along cornices or vertical edges; use pixel control for brand-color sequences or dynamic welcome effects; ensure power injection every 5-10m | IP65 rating withstands monsoon exposure in KPK and Punjab; aluminium housing resists corrosion in Karachi coastal salt-air conditions |
| Hospitality Venue Exterior Accents | Install along entrance canopies or pool edges; select RGB variant for event-themed color changes; coordinate with pixel controller for synchronized effects | Slim 30×20mm profile integrates discreetly with premium architecture in Lahore Gulberg and Islamabad DHA; 24V DC operation ensures safety in guest-accessible areas |
| Landmark Structure Outlines | Use warm/cool white variant for timeless architectural emphasis; program subtle breathing effects for evening presence; verify structural mounting compatibility | Pixel precision enables detailed highlighting of heritage features in Peshawar Museum or Sethi House projects; weather resilience critical for Pakistan’s diverse climate zones |
Applications
- Commercial Building Facade Highlighting — IP65 rating withstands monsoon exposure in KPK and Punjab; aluminium housing resists corrosion in Karachi coastal salt-air conditions
- Hospitality Venue Exterior Accents — Slim 30×20mm profile integrates discreetly with premium architecture in Lahore and Islamabad; 24V DC operation ensures safety in guest-accessible areas
- Landmark Structure Outlines — Pixel precision enables detailed highlighting of heritage features; weather resilience critical for Pakistan’s diverse climate zones from GB cold to Quetta heat
- Retail Signage & Brand Accents — RGB variant supports dynamic brand-color sequences for promotional campaigns; pixel control enables localized highlighting of logo elements
- Regional Adaptability — IP65 sealing + aluminium+PC construction ensures reliability in KPK monsoons, Balochistan heat (45°C+), GB cold snaps (-10°C), and Karachi coastal humidity when installed per specifications
🚚 Shipping & Delivery:
- Pakistan: Free shipping on orders ≥ PKR 15,000 | Dispatch 1–2 days | Nationwide delivery 2–5 days
- Installation: Mount fixture using appropriate hardware for substrate (concrete, metal, masonry); connect to 24V DC power supply via compatible pixel controller; all electrical connections must be performed by qualified electrician per Pakistan Electrical Safety Code; professional installation services available in Islamabad/Rawalpindi
FAQs
What control system is required for pixel addressing?
This pixel facade light requires a compatible pixel controller that supports individual pixel addressing (e.g., SPI, DMX, or proprietary protocol). The controller enables dynamic effects, color zoning, and sequencing across the 8 pixels per meter. Contact Voltedge via WhatsApp +92 343 9227883 for recommended controller models compatible with this fixture.
How do I select between warm white, cool white, or RGB variants?
This is a variable product with multiple CCT/RGB configurations. Specify your preferred output type (Warm White, Cool White, or RGB) when ordering via WhatsApp +92 343 9227883. Each variant uses the same aluminium+PC housing and IP65 rating but differs in LED chip configuration and control requirements.
Is this fixture suitable for coastal or high-humidity environments?
Yes. The IP65 rating certifies the enclosure is dust-tight and protected against water jets from any direction. This makes it suitable for Karachi coastal properties, KPK monsoon exposure, and high-humidity installations nationwide. For extended lifespan in salt-air environments, ensure regular maintenance and verify mounting hardware corrosion resistance.
What is the maximum run length for a single power injection?
The 12W/m power consumption at 24V DC allows for extended runs with proper voltage drop management. For precise calculations, consult Voltedge’s technical team with your project layout. Generally, power injection every 5-10 meters is recommended for consistent brightness across long facade installations.
🔧 Technical Details (Click to Expand)
- Pixel Addressing Architecture: Each of the 8 pixels per meter can be individually controlled via compatible pixel controller protocols (SPI, DMX, etc.). This enables architectural lighting designers to create detailed sequences, color gradients, and dynamic effects that highlight building features with precision — critical for landmark projects across Pakistan’s growing urban landscape.
- Aluminium+PC Thermal Management: The aluminium housing acts as a heatsink, conducting heat away from LED components to maintain performance and lifespan. The polycarbonate diffuser ensures uniform light output while protecting LEDs from environmental exposure. This combination is essential for reliable operation in Pakistan’s high-ambient temperature regions like Punjab summer and Quetta heat.
- IP65 Protection for Pakistan Climates: Precision gaskets and sealed cable entries achieve IP65 certification per IEC 60529. This multi-barrier approach prevents dust ingress (critical for industrial zones) and water penetration during monsoon exposure or coastal humidity — ensuring long-term reliability for facade installations nationwide.
- 24V DC Low-Voltage Safety: The 24V DC input voltage balances safety and efficiency. It reduces current draw compared to 12V systems (minimizing voltage drop in long runs) while remaining within extra-low voltage safety limits. Compatible with widely available 24V LED power supplies in Pakistan’s lighting supply chain, simplifying procurement for contractors.
